Figure 83: Testing bushing CT installed in a Power Transformer- A

CT Locations

Tests Set Connections

X1 X2 H1 H2

Jumpers

H1 Bushing

Secondary of H1

CT located in

control cabinet

H1 Bushing

H2 Bushing

H2 - H3

X1 - X2 - X3

H2 Bushing

Secondary of H2

CT located in

control cabinet

H2 Bushing

H3 Bushing

H3 - H1

X1 - X2 - X3

H3 Bushing

Secondary of H3

CT located in

control cabinet

H3 Bushing

H1 Bushing

H1 - H2

X1 - X2 - X3
