GASOLINE ENGINES BRAVO MODELS
Page 58 of 116
8. Depending upon boat configuration, follow instructions a., b. or c.:
CAUTION
Avoid exhaust hose failure. Discharge water from exhaust elbow must flow around
entire inside diameter of hose to avoid causing hot spots which could eventually
result in burned-through exhaust hoses. Exhaust hoses and/or tubes must be cor-
rectly connected to exhaust elbows so that they do not restrict the flow of discharge
water from exhaust elbow.
71653
Correct Connection Incorrect Connection
a. V8 Models - Through-Transom Exhaust: Tighten all exhaust hose and/or exhaust
tube clamps securely.
73961
a
a-Hose Clamps
