GASOLINE ENGINES BRAVO MODELS
Page 79 of 116
10. Lubricate O-ring seals with 2-4-C Marine Lubricant with Teflon.
72183
a
a-O-Ring Seals
11. Pull out shift linkage as far as it moves. Jaws will open, as shown.
72460
a
a-Shift Linkage
IMPORTANT: As sterndrive is inserted into sterndrive unit, entry of the bell housing
shift cable must be closely checked to make sure cable enters the jaws of shift link-
age assembly in the sterndrive.
