Mercusys AC12G User Manual

40
Chapter 4
4.7 Security
This function allows you to protect your home network from cyber attacks and
unauthorized users by implementing these network security functions.
4. 7. 1 Firewall
The SPI (Stateful Packet Inspection) Firewall protects the router from cyber attacks
and validate the trac that is passing through the router based on the protocol. This
function is enabled by default.
1. Visit http://mwlogin.net, and log in with the password you set for the router.
2. Go to Advanced > Security > Firewall, and congure the parameters as you need.
It’s recommended to keep the default settings.
4. 7. 2 Access Control
Access Control is used to block or allow specic client devices to access your
network (via wired or wireless) based on a list of blocked devices (Blacklist) or a list
of allowed devices (Whitelist).
I want to:
Block or allow specic client devices to access my network (via wired or wireless).
How can I do that?
1. Visit http://mwlogin.net, and log in with the password you set for the router.
2. Go to Advanced > Security > Access Control.
3. Select the access mode to either block (recommended) or allow the device(s) in
the list.
To block specic device(s):
1 ) Select Blacklist and click SAVE.

Mercusys AC12G Specifications

General

DSL WAN	No
Ethernet WAN	Yes
Product type	Tabletop router
Product color	Black
Transmit power	20 dBmW
Antennas quantity	4
Output current	0.85 A
Output voltage	9 V
Power source type	DC
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	1167 Mbit/s
WLAN data transfer rate (first band)	300 Mbit/s
WLAN data transfer rate (second band)	867 Mbit/s
Cables included	LAN (RJ-45)
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Security algorithms	WPA-PSK, WPA2-PSK
Certification	CE, ROHS
Package depth	288 mm
Package width	382 mm
Package height	66 mm
Package weight	760 g
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	140 mm
Width	222 mm
Height	32 mm
