Mercusys AC12G User Manual

69
AC1300 Wireless Dual Band Gigabit Router
AC12G
2. Congure the TCP/IP protocol
Now you have two ways to congure the TCP/IP protocol below:
Ǵ Setting IP address automatically
Select Obtain an IP address automatically, Choose Obtain DNS server automatically,
as shown in the Figure below:
Ǵ Setting IP address manually
a. Select Use the following IP address radio button. And the following items
available.
b. If the router's LAN IP address is 192.168.1.1, specify the IP address as
192.168.1.x (x is from 2 to 254), and Subnet mask is 255.255.255.0.
c. Enter the router’s LAN IP address (the default IP is 192.168.1.1) in the Default
gateway eld.
d. Select Use the following DNS server addresses radio button. In the Preferred
DNS Server eld you can type the DNS server IP address, which has been
provided by your ISP.

Mercusys AC12G Specifications

General

DSL WAN	No
Ethernet WAN	Yes
Product type	Tabletop router
Product color	Black
Transmit power	20 dBmW
Antennas quantity	4
Output current	0.85 A
Output voltage	9 V
Power source type	DC
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	1167 Mbit/s
WLAN data transfer rate (first band)	300 Mbit/s
WLAN data transfer rate (second band)	867 Mbit/s
Cables included	LAN (RJ-45)
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Security algorithms	WPA-PSK, WPA2-PSK
Certification	CE, ROHS
Package depth	288 mm
Package width	382 mm
Package height	66 mm
Package weight	760 g
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	140 mm
Width	222 mm
Height	32 mm
