Mercusys MW155R User Manual

MW155R
150Mbps Wireless N Router User Guide
-39-
 Target Description - Displays the description about the target and this description is unique.
 Information - The target can be IP address, port or domain name.
 Modify - To edit or delete an existing entry.
To add a new entry, follow the steps below.
1. Click Ad d .
2. In Mode field, select IP Address or Domain Name.
 If you select IP Address:
1) In Target Description field, create a unique description for the target (e.g.
Target_1).
2) In IP Address field, enter the IP address of the target.
3) Select a common service from Common Serv ice Port drop-down list, so that the
Target Port will be automatically filled. If the Common Serv ice Port drop-down list
doesn’t have the service you want, specify the Target Port manually.
4) In Protocol field, select ALL, TCP, UDP, or ICMP.

Mercusys MW155R Specifications

General

Brand	Mercusys
Model	MW155R
Category	Network Router
Language	English
