7.2 Reports
96
780/781 pH/Ion Meter, Manual
7.2 Reports
A pH/Ion Meter report is produced by transmitting data to a printer or
PC via the RS232 interface. In this way you can document e.g. measur-
ing results, calibration data, method parameters or the configuration of
the instrument in written form.
A requirement for a properly functioning report output is the input of the
receiving instrument (see Section 5.6) and the correct setting of the
RS232 transmission parameters (see Section 5.7).
The following reports can be automatically printed out after a meas-
urement has been made: a
is produced directly
with the
key. The automatic output of
calibration,
electrode test and result reports
must be defined as such under meth-
od parameters.
Apart from the measuring point report, all reports can be triggered
manually at a later date by the
key. A dialog appears for
the selection of the required report with the
keys:
user memory Report of the memory occupancy by methods and
calibration data
calib short Calibration report without graphical calibration
function curve
calib full Calibration report with graphical calibration func-
tion curve
config Instrument configuration report
param Current method parameters report
result short Measuring result report for standard or sample
addition without graphical presentation
(781 pH/Ion Meter only)
result full Measuring result report for standard or sample
addition with graphical presentation
(781 pH/Ion Meter only)
el.test pH electrode test report (see Section 8.6)
mv memory Output of all stored measured values
all Output of all existing reports
During selection these reports can also be selected directly by using
the key which has the corresponding function (e.g.
for a
calibration report).
