2.3 Connecting optional devices
10
780/781 pH/Ion Meter, Manual
2.3.2 Connecting the 802 Rod Stirrer
The
802
Rod Stirrer
, in combination with the
804
Ti Stand,
can also be
connected directly to the pH/Ion Meter. This is done by plugging the
MSB connection cable of the 804 Ti Stand into MSB connection
9
of the
pH/Ion Meter:
Fig. 8: 780 pH Meter / 781 pH/Ion Meter – 802 Rod stirrer
