Technical data Page 17
Product Manual / Mounting Instructions „Servo drives ARS 2320 FS, ARS 2340 FS and ARS 2360W FS“ Version 1.0
Ambient conditions and qualification
Feature
Value
Pollution degree
2
The integrated safety equipment requires compliance with pollution
degree 2 and thus a protected fitting space (IP54). This must
always be ensured through appropriate measures, e.g. through
installation in a control cabinet.
CE conformity:
see appendix in chapter 13
Low-voltage directive
2014/30/EU
verified by application of the harmonised standard EN 61800-5-1
EMC directive
2014/35/EU
verified by application of the harmonised standard EN 61800–3
Machinery directive
2006/42/EG
see EC Type-Examination Certificate
cULus certification
Listed according to UL 61800-5-1, C22.2 No. 274-13
(on request)
Dimensions and weight
Feature
ARS 2320 FS
ARS 2340 FS
ARS 2360W FS
Dimensions including the mounting
plate and screw heads (H x W x D)
*)
390 x 93 x 263 mm
3
390 x 165 x 263
mm
3
390 x 163 x 186
mm
3
Housing dimensions (H x W x D)
351 x 90,5 x 256,5
mm
3
351 x 162,5 x 256,5
mm
3
351 x 161 x 180
mm
3
Weight
ca. 8 kg
ca. 13,5 kg
ca. 9 kg
*) Dimensions without mating plugs
4.2 Mains [X9]
Performance data [X9], [X9B], [X9C]
Feature
ARS 2320 FS
ARS 2340 FS
ARS 2360W FS
Supply voltage X9
3 x 230 ... 480 VAC [+/- 10%], 50…60 Hz
Max. mains current for continuous
operation
18 A
RMS
36 A
RMS
40 A
RMS
Intermediate circuit voltage
for a supply voltage of 400 VAC
X9C
560 ... 570 VDC
24VDC supply X9B
24 VDC [± 20%] (max. 1 A) *)
*) plus current consumption of a possibly connected holding brake and I/Os
