Electrical installation Page 75
Product Manual / Mounting Instructions „Servo drives ARS 2320 FS, ARS 2340 FS and ARS 2360W FS“ Version 1.0
Mating plug X19
INFORMATION
Mating plug
ARS 2320/40/60W FS
X19
USB-connector (male), type B
Recommended cable type or comparable:
 Interface cable for the USB interface, 4 cores, shielded and twisted. In order to set up a USB
connection, it is mandatory to use a twisted and shielded (4-core) cable since, otherwise, the
transmission may be subject to interferences. In addition, it must be ensured that the cable has a
wave impedance of 90 Ω.
8.14 SD/SDHC/MMC card slot
The ARS 2300 FS servo drive comprises a SD-Card slot for the support of Firmware downloads and
uploads and downloads of parameter sets.
Pin assignment SD card
Pin No.
Name
SD mode
SPI mode
1
DATA3/CS
Data line 3 (bit 3)
Chip select
2
CMD/DI
Command/response
Host to card commands and data
3
Vss1
Supply voltage earth (ground)
Supply voltage earth (ground)
4
Vcc
Supply voltage
Supply voltage
5
CLK
Clock
Clock
6
Vss2
Supply voltage earth (ground)
Supply voltage earth (ground)
7
DAT0/DO
Data line 0 (bit 0)
Card to host data and status
8
DAT1
Data line 1 (bit 1)
Reserved
9
DAT2
Data line 2 (bit 2)
Reserved
