Page 32 Functional safety technology
Product Manual / Mounting Instructions „Servo drives ARS 2320 FS, ARS 2340 FS and ARS 2360W FS“ Version 1.0
CAUTION!
The function STO as a sole safety function is not sufficient for drives under permanent
torque, such as hanging loads.
CAUTION!
For drives, the function must be validated after installation and after any changes of the
installation.
This validation must be documented by the commissioning engineer.
6.6.2 Pin assignment MOV [X40]
Pin assignment X40 MOV
Pin
Designation
Description (factory setting
1)
)
X40A plug connector
1
DIN40A
Digital input 40, two-channel
(Factory setting: Emergency stop switching device, STO and SBC request)
2
DIN40B
3
DIN42A
Digital input 42, two-channel
4
DIN42B
5
DOUT40A
Digital output 40, two-channel
6
DOUT40B
7
DIN44
Digital input 44
(Factory setting: Brake feedback)
8
DIN45
Digital inputs 45, 46, 47
(Factory setting: Mode selector switch)
9
DIN46
10
DIN47
11
DIN48
Digital input 48
(Factory setting: Error acknowledgement).
12
DIN49
Digital input 49
(Factory setting: Terminate safety function on rising edge).
X40B plug connector
13
DIN41A
Digital input 41, two-channel
14
DIN41B
15
DIN43A
Digital input 43, two-channel
16
DIN43B
17
DOUT41A
Digital output 41, two-channel
18
DOUT41B
19
DOUT42A
Digital output 42, two-channel
20
DOUT42B
