6.6 FSM 2.0 – MOV
Please refer to the original instructions "FSM 2.0 – MOV" for further information.
Figure 5: MOV module: front view
6.6.1 Features
The Functional Safety Module FSM 2.0 – MOV serves as an expansion of the Servo drive ARS 2000 FS
to implement the safety functions:
 STO – Safe Torque Off
 SS1 – Safe Stop 1
 SS2 – Safe Stop 2
 SOS – Safe Operating Stop
 SLS – Safely-Limited Speed
 SSR – Safe Speed Range
 SSM – Safe Speed Monitor
 SBC – Safe Brake Control
 When suitable position transmitters are used and with suitable activation of the safety module, the
requirements are fulfilled in accordance with EN 61800-5-2 up to and including SIL3 and in
accordance with EN ISO 13849-1 up to and including Category 4 / PL e.
Depending on the encoders used for position recording, it is possible that only SIL2 is implemented
 It is equipped with a floating feedback contact.
 It can be simply plugged into the basic unit from the outside, so that it can be used for upgrading
systems that are already equipped with ARS 2100 FS Servo drives.
 It is exclusively suitable for the ARS 2000 FS product range.
 It offers a user-friendly parameterisation with the Metronix ServoCommander
®
software with including
the SafetyTool.
