Internal brake resistor [X9A]
Feature
ARS 2320 FS
ARS 2340 FS
ARS 2360W FS
Brake resistance
30 
15 Ω
Pulse power
18 kW
36 kW
Continuous power
80 W
160 W
Operating threshold
760 V
External brake resistor [X9A]
Feature
ARS 2320 FS
ARS 2340 FS
ARS 2360W FS
Brake resistance external
15 Ω ≤ R
Extern
≤ 50 Ω
Continuous power
 5 kW
 10 kW
Permissible operating voltage
 800 V
4.3 Motor connector [X6]
Motor connection specifications [X6]
Feature
ARS 2320 FS
ARS 2340 FS
ARS 2360W FS
Specifications for operation with 3x 400 VAC, 50 Hz, with an output stage clock frequency of 8 kHz
Output power
12 kVA (8 kW)
24 kVA (16 kW)
26 kVA (18 KW)
Max. output power for 3 s
30 kVA
60 kVA
65 kVA
Output current
20 A
RMS
40 A
RMS
60 A
RMS
Max. output current for 3 s
50 A
RMS
100 A
RMS
150 A
RMS
Derating at PWM = 16 kHz:
Output current
14 A
RMS
28 A
RMS
42 A
RMS
Derating at PWM = 16 kHz:
Max. output current for 3 s
35 A
RMS
70 A
RMS
105 A
RMS
Output stage clock frequency
4…16 kHz (software programmable)
As a guideline: Power
loss/efficiency (with regard to the
rated output power)
typical 5% / 95%
In deviation from the technical motor data, the ARS 2300 FS servo drives have a current derating during
nominal operation. The rated current and the duration of the maximum permissible peak current of the
ARS 2300 FS servo drive depend on several factors.
These factors are:
 Output current level (the higher the output current is, the shorter the permissible time will be)
 Clock frequency of the power output stage (the higher the clock frequency is, the shorter the
permissible time will be)
 Electrical rotational frequency of the motor (speed multiplied by the number of pole pairs) (the
higher the rotational frequency is, the longer the permissible time will be)
