CAUTION!
For drives, the function STO must be validated after installation and after any changes
of the installation.
This validation must be documented by the commissioning engineer.
6.5.2 Pin assignment STO [X40]
Pin assignment X40 STO
Pin no.
Name
Value
Specification
8
0V
0 V
Reference potential for internal controller supply
7
24V
+24 V DC
24 V supply out
6
C2
Feedback contact for the state “STO” to an
external control
5
C1
4
0V_B
0 V
Reference potential for STOB
3
STOB
0 V / 24 V
Control input B for the function STO
2
0V_A
0 V
Reference potential for STOA
1
STOA
0 V / 24 V
Control input A for the function STO
INFORMATION
The functionality of the DIP switches is identical to the functionality of the DIP switches
of the module FSM 2.0 – FBA.
