7.8 Water cooling system for ARS 2360W FS
The technical data and the requirements for the cooling circuit are shown in chapter 4.
The following examples for water cooling systems can be obtained from the manufacturers specified
below.
Please use the mounting dimensions for the drill holes as described in chapter 7.7
Figure 18: Water cooling system – example by the manufacturer Dau
Address:
DAU Ges.m.b.H & Co.KG
Dietenberg 38
A-8563 Ligist / Austria
Tel.: +43 (0)31 43 23 51-0
Fax: +43 (0)31 43 23 51-14
Mobile: +43 676 6060022
www.dau-at.com
