MICRO-EPSILON scanCONTROL 30 Series User Manual

Page 15
Functional Principle, Technical Data
scanCONTROL 30xx
3.2 Technical Data
Model LLT 30x0-25 LLT 30x0-50 LLT 30x0-100 LLT 30x0-200
Laser type
Red Laser |
Blue Laser
Red Laser |
Blue Laser
Red Laser |
Blue Laser
Red Laser
z-axis
Measuring range
Start of measuring range 77.5 mm 105 mm 200 mm 200 mm
Mid of measuring range 85 mm 125 mm 270 mm 310 mm
End of measuring range 92.5 mm 145 mm 340 mm 420 mm
Height of measuring range 15 mm 40 mm 140 mm 220 mm
Extended measuring
range
Start of measuring range - - 190 mm 160 mm
End of measuring range - - 360 mm 460 mm
Max. deviation of a
single point
1
(2sigma)
Red Laser ±0.07 % ±0.07 % 0.06 % ±0.10 %
Blue Laser ±0.06 % ±0.06 % 0.05 % -
Line linearity
1 2
1.5 µm 3 µm 9 µm 26 µm
±0.01 % ±0.0075 % ±0.006 % ±0.012 %
x-axis
Measuring range
Start of measuring range 23.0 mm 43.3 mm 75.6 mm 130 mm
Mid of measuring range 25.0 mm 50.0 mm 100.0 mm 200 mm
End of measuring range 26.8 mm 56.5 mm 124.4 mm 270 mm
Extended measuring
range
Start of measuring range - - 72.1 mm 100 mm
End of measuring range - - 131.1 mm 290 mm
Resolution 2,048 points/profile
Profile frequency up to 10,000 Hz
Interfaces
Ethernet GigE Vison Output of measurement values / Sensor control / Profile data transmission
Digital inputs Mode switching / Encoder (counter) / Trigger
RS422 (half-duplex)
3
Output of measurement values / Sensor control / Trigger / Synchronization
