Page 36
Installation and Mounting
scanCONTROL 30xx
5.3 Installation Instructions
- Only use shielded cables from the accessories for all connection cables.
- Connect the cable shields to the potential equalization on the evaluation unit (switch cabinet, PC housing, connector housing) and
avoid ground loops.
- Lay all connection cables in accordance with the generally applicable measuring technology regulations, i.e. for example not direct-
ly next to pulse-carrying lines, preferably in a separate cable duct.
- The minimum bending radii of the recommended cables for flexible laying must not be less 80 mm.
- MICRO-EPSILON recommends the use of the optionally available power supply PS2020, Din rail mounting, input 230 VAC, output
24 VDC/2.5 A, see Appendix.
5.4 Getting Ready for Operation, Initial Operation
Mount the sensor according to the installation instructions, see Chap. 5.1.
Connect the sensor to the Ethernet cable.
Connect the sensor to downstream display or monitoring units and to the power supply.
The sensor must only be connected to the peripheral equipment when disconnected from the power supply, i.e
only when the operating voltage is switched off.
Switch on the power supply.
