Page 38
Operation of the Sensor with a PC
scanCONTROL 30xx
6.3 Installation
6.3.1 Requirements
The following minimum system specification is necessary for the operation of the scanCONTROL software packages:
scanCONTROL Configuration Tools
- Windows 7, Windows 8 oder 8.1, Windows 10 (each 32 bit and 64 bit)
- 1-GHz or faster (32 bit und 64 bit) processor / 1 GB RAM (recommended 4 - 8 GB)
- Screen resolution: 1024 x 768 (recommended 1920 x 1080)
scanCONTROL 3D-View
- Windows 8 or 8.1, Windows 10 (each 64 bit)
- 1-GHz or faster (64 bit) processor / 1 GB RAM (recommended 16 GB)
- Screen resolution: 1024 x 768 (recommended 1920 x 1080)
- Graphics card / GPU with OpenGL 3.1 or higher
Connect the sensor directly to the PC. Please do not use any hubs or switches.
If your network card supports “VLAN” option, please deacivate it.
To operate the sensor, the PC and the sensor must be in the same subnet.
To be able to use the software the following steps must be followed:
1. Install the Ethernet interface hardware, if not already installed.
2. Install the software.
3. Connect the scanCONTROL 30xx measuring system to the PC via Ethernet.
6.3.2 Connecting scanCONTROL 30xx to the PC
Proceed as follows in order to connect scanCONTROL 30xx via Ethernet with the PC.
Finish the installation of the software completely.
Connect scanCONTROL 30xx via the Ethernet interface to the PC and switch on the power supply.
Please wait until the scanCONTROL 30xx measuring system is recognized by the PC. This may take a few seconds.
The system is now ready to operate the scanCONTROL 30xx measurement system with scanCONTROL Configuration Tools.
