2D/3D Output Unit
scanCONTROL 30xx
System data
Max. number of bus sharing unit Limited by Ethernet specification
Max. length of fieldbus segment 100 m
Baud rate 10/100 Mbit/s
Technical Data
Number of bus terminals 64
With bus extension 250
Power supply DC 24 V (-25 % ... +30 %)
Max. input current 280 mA at 24 V
Internal current consumption 450 mA at 5 V
Total current for I/O modules 700 mA at 5 V
Voltage drop at I
max.
< 1 V at 64 I/O modules
Fig. 29 Technical data Fieldbus Coupler/Ethernet
7.4.2 Supported Modules
- 8-Channel digital output module; DC 24 V; 0.5 A; high-side switching; 8 actors; short-circuit prooved; Micro-Epsilon order no.
0325115, see Chap. 7.4.3; power supply through power jumper contacts
- 8-Channel digital output module; DC 24 V; 0.5 A; low-side switching; 8 actors; short circuit prooved;
Micro-Epsilon order no. 0325131; power supply through power jumper contacts
- 4-Channel analog output module; 0 - 10 V; Micro-Epsilon order no. 0325135, see Chap. 7.4.4
- 4-Channel analog output module; ±10 V; Micro-Epsilon order no. 0325116
- 4-Channel analog output module; 0 – 20 mA; Micro-Epsilon order no. 0325132
- 4-Channel analog output module; 4 – 20 mA; Micro-Epsilon order no. 0325133
