Page 18
Functional Principle, Technical Data
scanCONTROL 30xx
Model LLT 30x2-25 LLT 30x2-50 LLT 30x2-100 LLT 30x2-200
Laser type
Red Laser |
Blue Laser
Red Laser |
Blue Laser
Red Laser |
Blue Laser
Red Laser
Output of measurement values
Ethernet (UDP / Modbus TCP); RS422 (ASCII / Modbus RTU)
analog
4
; switch signal
4
; PROFINET
5
; EtherCAT
5
; EtherNet/IP
5
Control and display elements 3x color LEDs for laser, data and error
Light source
Red Laser
≤ 10 mW ≤ 12 mW
Standard: laser class 2M, semiconductor laser 658 nm
≤ 30 mW ≤ 50 mW
Option: laser class 3R, semiconductor laser 658 nm
Blue Laser
≤ 10 mW
Standard: laser class 2M, semiconductor laser 405 nm
Laser switch-off via software, hardware switch-off with /SI option
Aperture angle of laser line 23° 28° 30° 45°
Permissible ambient light
(fluorescent light)
1
10,000 lx
Protection class (DIN EN 60529) IP67 (when connected)
Vibration (DIN EN 60068-2-27) 2 g / 20 … 500 Hz
Shock (DIN EN 60068-2-6) 15 g / 6 ms
Temperature range Storage: -20 … +70 °C; Operation: 0 … +45 °C
Weight 415 g (without cable)
Supply voltage
11 … 30 VDC, nominal value 24 V, 500 mA,
IEEE 802.3af class 2, Power over Ethernet (PoE)
1) Based on measuring range; measuring object: Micro-Epsilon standard object 4) Only with 2D/3D Output Unit
2) According to a one-time averaging over the measuring field (1,024 points) 5) Only with 2D/3D Gateway
3) RS422 interface, programmable either as serial interface or as input for triggering/
synchronization
