Workstation 4 Setup Guide B-1
Appendix B
Connector and Cable Diagrams
On the pages that follow, you will find diagrams of the Workstation
4 I/O Panel connectors, system board connectors, and commonly
used hook-up cables. A description of how each cable or connector is
used is provided.
In this appendix
IO Panel Connectors .......................................................................B-2
System Board Connectors.............................................................. B-7
Hook-up Cables ..............................................................................B-8
