What is The Workstation 4?
Specifications
Specifications
The Workstation 4 conforms to the following specifications.
Specification Parameters
Processor AMD Geode SC3200 WebPad on a Chip
Cache 16KB Unified L1 Cache (No L2 Cache)
Display 12.1” Active LCD Panel (800x600)
Touchscreen Microtouch/3M Five-wire resistive, 100 thousand
points-per-inch resolution rated at a screen life of over
35 million touches.
Backlight(s) Can be set to one of 120 intensity levels along with three
preset intensity levels
Real Time Clock Software compatible with DS1287 and MC146818.
100-year calendar with alarm features and century
roll-over, includes 242 bytes of battery backed CMOS
RAM.
Memory One 168-Pin DIMM socket supports 32 MB to 256 MB
of PC133 SDRAM (+3.3V, Unbuffered)
Mag Stripe Reader 3-Track ABA compatible, operates in MAGTEK and
Special modes.
Customer Displays Optional 2 x 20 VFD or 240x64 graphics based LCD
available in both integrated and pole mount versions.
USB Ports Two external UHCI 1.1 compliant USB ports
LAN Interface On-Board National DP83815 Ethernet Controller
supports 10BaseT (IEEE 802.3) or 100BaseT (IEEE
802.3u) using twisted pair cabling.
Serial Ports 1 DB9 RS232 Serial /w handshake, 2 Modular TX/RX
RS232 Serial, no handshake.
Input Voltage Universal Input - 85 to 264VAC, 47 to 63Hz.
Input Power 65W Max
BTU/Hour 104.3 (Typical) 222 (Maximum)
Storage Temperature -25°C (-13°F) to 85°C (185°F)
Operating Temperature 0°C (32°F) to 45°C (113°F), 90% relative humidity max
Weight 7.75 lb. (3.5 kg) / Shipping weight 11 lb. (5 kg)
Case Material ABS Plastic
Physical Dimensions See Appendix A
