123
www.roadwidener.com
Model SP-8 & 10
NO REQ DESCRIPTION PART
NUMBER
** 75 1 6-100R1AT-6FJS-6FJS90S-120.0
(STEERING MOTOR T TO TRAC DRIVE
MOTOR BOTTOM LOOP FLUSH)
SP-769-75
** 76 1 6-100R1AT-6FJS-6FJS-59.0 (TRAC
DRIVE TOP LOOP FLUSH TO RETURN
MANIFOLD)
SP-769-76
** 77 1 6-100R1AT-6FJS-6FJS-166.0 (STACK
VALVE P2 TO STEERING MOTOR P)
SP-769-77
** 78 1 6-100R1AT-6FJS-6FJS-150.0 (STEERING
MOTOR R TO AXLE CYL R/S)
SP-769-78
** 79 1 6-100R1AT-6FJS-6FJS90S-160.0
(STEERING MOTOR L TO AXLE CYL L/S)
SP-769-79
** 80 1 6-100R1AT-6FJS-6FJS90S-63.0 (STACK
VALVE RB TO B/H TEE FOR REAR
BRAKES)
SP-769-80
** 81 1 6-100R1AT-6FJS90S-6FORS45-20.0 -
135° OFFSET (REAR BRAKE L/H FROM
B/H TEE)
SP-769-81
** 82 1 6-100R1AT-6FJS-6FORS45-30.0 (REAR
BRAKE R/H FROM B/H TEE)
SP-769-82
** 83 1 6-100R1AT-6FJS-6FJS90S-104.0 (STACK
VALVE SB TO PRESS IN B/H R/S)
SP-769-83
** 84 2 6-100R1AT-6FJS-6FJS-40.0 (CROSS
HOSES AT FRNT B/H UNDER DECK T&P)
SP-769-84
** 85 1 6-100R1AT-6FJS-6FJS90S-21.0 (L/S B/H
B TO SHUTTLE VALVE A)
SP-769-85
** 86 1 6-100R1AT-6FJS-6FJS-33.0 (R/S B/H B
TO SHUTTLE VALVE B)
SP-769-86
** 87 1 6-100R1AT-6FJS-6FJS90S-73.0 (TANK
B/H R/S TO RETURN MANIFOLD)
SP-769-87
** 88 1 6-100R1AT-6FJS-6FJS90S-24.0 (LOAD
SHUTTLE VALVE C TO SERVICE BRAKE
TEE @ AXLE)
SP-769-88
** 89 1 6-100R1AT-6FJS-6FJS90S-28.0 (LOOP
HOSE @ SERVICE BRAKE FRONT AXLE
REAR PORTS)
SP-769-89
** 90 1 6-100R1AT-6FJS-6FJS90L-41.0 (L/S
BRAKE PEDAL T TO L/S B/H T)
SP-769-90
** 91 1 6-100R1AT-6FJS-6FJS90L-38.0 (L/S
BRAKE PEDAL P TO L/S B/H P)
SP-769-91
** 92 1 6-100R1AT-6FJS-6FJS-24.75 (L/S BRAKE
PEDAL B TO L/S B/H B)
SP-769-92
** 93 1 6-100R1AT-6FJS-6FJS90L-46.0 (R/S
BRAKE PEDAL P TO R/S B/H P)
SP-769-93
** 94 1 6-100R1AT-6FJS-6FJS90L-49.0 (R/S
BRAKE PEDAL T TO R/S B/H T)
SP-769-94
** 95 1 6-100R1AT-6FJS-6FJS-38.25 (R/S BRAKE
PEDAL B TO R/S B/H B)
SP-769-95
** 96 1 6-100R1AT-6FJS-6FJS90S-23.0 (DIR
CTRL VALVE 1 TO RETURN MANIFOLD)
SP-769-96
** 97 1 6-100R1AT-6FJS-6FJS90L-69.0 (DIR
CTRL VALVE 2 TO PARKING BRAKE ON
AXLE FRONT PORTS)
SP-769-97
** 98 1 6-100R1AT-6FJS-6FJS90S-38.0 (MPT
CHARGE PUMP TO DIR CTRL VALVE 3)
SP-769-98
** 99 1 6-100R1AT-6FJS-6FJS90S-21.0 (LOOP
HOSE AT PARKING BRAKE FRONT AXLE
FRONT PORTS)
SP-769-99
** 100 1 12-100R4 x 24.0 (GEAR PUMP SUCTION) SP-769-100
** 101 1 8-100R1AT-8FJS-8FJS-37.0 (GEAR PUMP
TO FILTER)
SP-769-101
** 102 1 8-100R1AT-8FJS-8FJS-15.0 (FILTER TO
STACK VALVE P1)
SP-769-102
** 103 1 8-100R1AT-8FJS-8FJS90S-31.5 (STACK
VALVE T1 TO RETURN MANIFOLD)
SP-769-103
NO REQ DESCRIPTION PART
NUMBER
** 104 1 20-100R4 x 53.0 (MPT PUMP SUCTION) SP-769-104
** 105 1 12-100R12-12FJS-12FJS-30.0 (MPT
PUMP D PORT TO HOT OIL SHUTTLE)
SP-769-105
** 106 1 12-100R12-12FJS-12FJS-33.0 (MPT
PUMP C PORT TO HOT OIL SHUTTLE)
SP-769-106
** 107 2 12-100R12-12FJS-12FJS-140.0 (HOT OIL
SHUTTLE TO CONV MOTOR)
SP-769-107
** 108 1 6-100R1AT-6FJS-6FJS90L-21.0 (HOT OIL
SHUTTLE TO RETURN MANIFOLD)
SP-769-108
** 109 2 12-100R15-12FJS-62SF45-89.0 (6,000
PSI W/P) (TRACTION DRIVE HOSES)
SP-769-109
** 110 2 6-100R1AT-6FJS-6FJS90S-120.0 (STACK
VALVE A (G & S) TO BULKHEAD)
SP-769-110
** 111 2 6-100R1AT-6FJS-6FJS90L-120.0 (STACK
VALVE B (G & S) TO BULKHEAD)
SP-769-111
** 112 1 6-100R1AT-6FJS-6FJS90S-176.0 (STACK
VALVE A (EXT) TO BULKHEAD @
COLUMN)
SP-769-112
** 113 1 6-100R1AT-6FJS-6FJS90L-176.0 (STACK
VALVE B (EXT) TO BULKHEAD @
COLUMN)
SP-769-113
** 114 2 6-100R1AT-6FJS-6FJS-75.0 (GRADE
BULKHEAD TO CYLINDER)
SP-769-114
** 115 1 6-100R1AT-6FJS-6FJS-132.5 (SLOPE
BULKHEAD TO CYLINDER)
SP-769-115
** 116 1 6-100R1AT-6FJS-6FJS-131.0 (SLOPE
BULKHEAD TO CYLINDER)
SP-769-116
** 117 1 12-100R2AT-12FJS-12FJS90L-46.0 (MPT
PUMP CASE DRAIN TO TANK)
SP-769-117
** 119 1 6-100R1AT-6FJS-6FJS-17.5 (HOSE AT
GRADE CYL)
SP-769-119
** 120 1 6-100R1AT-6FJS-6FJS-19.75 (SLOPE
CYL (DN) TOP TEE TO VALVE V2)
SP-769-120
** 121 1 6-100R1AT-6FJS-6FJS-18.5 (SLOPE CYL
(UP) SIDE TEE TO VALVE V1)
SP-769-121
** 122 1 12-100R2AT-12FJS-12FJS-97.0 (RETURN
MANIFOLD TO OIL COOLER)
SP-769-122
** 123 1 12-100R2AT-12FJS-12FJS-89.0 (OIL
COOLER TO TANK)
SP-769-123
** 125 1 12-100R12-12FJS-12FJS90S-60.0 (CONV
MOTOR THRU FRAME TUBE)
SP-769-125
** 126 1 12-100R12-12FJS-12FJS90L-62.0 (CONV
MOTOR THRU FRAME TUBE)
SP-769-126
127 REF 6-100R1AT-6FJS-6FJS90S-193.0 SP-751-02
128 REF 6-100R1AT-6FJS-6FJS90L-163.0 SP-751-03
* 129 2 ADAPTER, STRAIGHT, 1-1/16-12 MJIC x
1-1/16-12 MJIC
2027-12-12S
* 131 1 ADAPTER, 90° ELBOW, 9/16-18 MJIC x
M 14-1.5 METRIC MALE
7205-06-14-
NWO
* These items are part of Fitting Kit SP-769 -FK Rev-C.
** These items are part of Hose Kit SP-769 -HK Rev-A.
Item 19 , 127 and 128 are reference parts and not part of the assembly.
Item 130 is used with Poclain Brake Pedals
