Model SP-8 & 10
NO REQ DESCRIPTION PART NUMBER
1 1 CHASSIS BODY & FRAME ASSEMBLY, (SP-8) SP-715
2 2 HAND RAIL STUDS (FRONT) SP-043
3 1 FRONT SIDE RAILING (L H) SP-044
4 1 FRONT SIDE RAILING (R H) SP-045
5 1 OPERATOR SEAT ASSEMBLY SP-135
6 REF FRONT DECK EXT WELDMENT (R.S.) SP-173
7 REF FRONT DECK EXT WELDMENT (L.S.) SP-174
8 1 MANUAL SHIFT ASSEMBLY SP-534
9 2 TRANS SUPPORT WELDMENT SP-529
10 10 HEX NUT, 5/16-18 HXN-5/16
11 4 HEX HD CAP SCREW 7/8-9 UNC x 8 HCS-7/8-9-8.00
12 4 FLAT WASHER, 7/8 FLW-7/8
13 4 LOCK WASHER, 7/8 LKW-7/8
14 4 HEX NUT, 7/8-9 UNC HXN-7/8-9
15 10 FLAT SOCKET HD CAP SCREW 5/16-18 UNC x 1 FCS-5/16-18-1.00
16 12 FLAT SOCKET HD CAP SCREW 3/8-16 UNC x 1.25 FCS-3/8-16-1.25
17 6 FLAT WASHER, 3/8 FLW-3/8
18 22 LOCK WASHER, 3/8 LKW-3/8
19 22 HEX NUT, 3/8-16 UNC HXN-3/8-16
20 6 HEX HD CAP SCREW 1/2-13 UNC x 4-1/2 HCS-1/2-13-4.50
21 17 LOCK WASHER, 1/2 LKW-1/2
22 17 HEX NUT, 1/2-13 UNC HXN-1/2-13
23 11 FLAT WASHER, 1/2 FLW-1/2
24 2 HEX HD CAP SCREW 3/8-16 UNC x 2-1/2 HCS-3/8-16-2.50
25 2 TIRE,11R22.5 T-501-5
26 2 WHEEL, 10 HOLE RIM T-501-4
27 REF WHEEL NUT 3/4-16 UNF R/H THREAD M17044
28 REF WHEEL NUT 3/4-16 UNF L/H THREAD M17045
29 2 TIRE, 425/65/R22.5 M18022
30 2 WHEEL, BLACK, 12.25 x 22.5 (SP-8 & 10, FRONT) SP-065
31 1 AXLE, DRIVE / STEERING M18103
32 4 SP-530 REV-A “ U-BOLT ASSY” CONSISTS OF: M11089
33 10 LOCK WASHER, 5/16 LKW-5/16
34 1 TRAILER AXLE & BRAKE ASSY SP-144
35 8 HEX HD CAP SCREW (METRIC) 14 x 2.0 x 40 HCS-M-14-2.0-40
36 8 LOCK WASHER (METRIC) 14 LKW-M-14
37 REF CENTER DECK WELDMENT SP-052
38 8 HEX HD CAP SCREW 3/8-16 UNC x 2-1/4 HCS-3/8-16-2.25
39 1 HYDRAULIC MOTOR, TRACT DR (SP-8 SN:390 - 395) M9072A
40 1 RAILING, RIGHT CENTER DECK SP-1173
41 4 HEX HD CAP SCREW (METRIC) 14 x 2.0 x 35 HCS-M-14-2.0-35
42 4 WASHER, SERRATED BELLEVILLE, 9/16, 0.591 ID x 0.866 OD M1345
43 1 LOCK ASSY, CAM, KEYED TO CH513, W/ 2 KEYS M5035
44 1 COVER, KEY SEALING, M210011
45 1 RAILING, LEFT CENTER DECK SP-1174
9.1 CHAssIs AssemBly (sp-8 & spd-8), sp-005 rev-f
