Midland SP-8 - Push Roller Assembly SP-151 Rev-A

73
www.roadwidener.com
Model SP-8 & 10
10.6 pusH roller AssemBly sp-151 rev-A
DETAIL A
No REQ DESCRIPTION PART NUMBER
1 1 PUSH ROLLER BEAM WLDMT SP-152
2 1 PUSH ROLLER MOUNT S-1282
3 2 ROLLER TUBE 800-051
4 2 ROLLER SHAFT 800-052
5 4 WIDE INNER RING BEARING W/COLLAR 1-15/16 BORE M0157
6 4 FLAT HEAD CAP SCREW 5/8-11 UNC x 1-1/2 FCS-5/8-11-1.50
7 1 PIVOT PIN S-323
8 1 HITCH PIN CLIP FOR 1-1/8 - 1-1/2 DIA SHAFT .243 DIA SHAFT 0.243 DIA WIRE M12101
