67
www.roadwidener.com
Model SP-8 & 10
NO REQ DESCRIPTION PART NUMBER
1 1 HOPPER FRAME SUB-
ASSEMBLY
SP-784
2 2 WIPER FRAME WELDMENT SP-811
3 2 BIB ASSEMBLEY SP-718
4 2 DEFLECTOR PLATE
INSTALLATION
SP-717
5 1 COVER (HYD HOSES) SP-560
6 2 ADJUSTABLE DISCHARGE
GATE INSTAL.
SP-276
7 1 HOPPER END-LEFT SIDE SA-444-02
8 1 HOPPER END-RIGHT SIDE SA-444-01
9 2 DRIVE ROLLER SA-440
10 1 CONVEYOR BELT ASSY, W/
ROLLER CHAIN
SA-1593
11 30 ROLLER SA-1147
12 2 RETAINER - WIPER SA-055
13 2 WIPER RUBBER SA-043
14 4 MOTOR MOUNT KEEPER S-437
15 2 HYDRAULIC MOTOR MOUNT S-436
16 2 DRIVE SHAFT COUPLING S-435
17 2 SIDE BOARD RUBBER ASSY
(INTERIOR)
S-427
18 1 RETAINER, CENTER BIB S-426
19 1 CENTER BIB S-425
20 1 BUMPER & GUIDE WELDM’T S-422
21 2 SIDE BOARD RUBBER W/
NOTCHES (EXTERIOR)
S-1612
22 1 REAR SIDE BOARD S-1399
23 1 FRONT SIDE BOARD S-1398
24 4 CLAMP, RUBBER SIDEBOARD S-1382
25 2 MOTOR HYDRAULIC (CONV.
DRIVE)
M8033
26 2 BEARING, TAKE-UP SC 2”
BORE
M0146
27 17 LOCK WASHER, 5/16 LKW-5/16
28 20 LOCK WASHER, 3/8 LKW-3/8
29 10 LOCK WASHER, 3/4 LKW-3/4
30 44 LOCK WASHER, 1/2 LKW-1/2
31 8 HEX NUT, 3/8-16 UNC HXN-3/8-16
32 6 HEX NUT, 3/4-10 UNC HXN-3/4-10
33 18 HEX NUT, 1/2-13 UNC HXN-1/2-13
34 4 HEX JAM NUT, 7/8-9 UNC HJN-7/8-9
35 8 HEX HD CAP SCREW, 5/16-18
UNC-1 3/4
HCS-5/16-18-1.75
36 12 HEX HD CAP SCREW, 3/8-16
UNC x 2
HCS-3/8-16-2.00
37 8 HEX HD CAP SCREW, 3/8-16
UNC X 1 3/4
HCS-3/8-16-1.75
38 6 HEX HD CAP SCREW, 3/4-10
UNC x 6
HCS-3/4-10-6.00
39 2 HEX HD CAP SCREW 3/4-10
UNC x 3-1/2
HCS-3/4-10-3.50
40 2 HEX HD CAP SCREW 3/4-10
UNC x 2-1/2
HCS-3/4-10-2.50
NO REQ DESCRIPTION PART NUMBER
41 2 HEX HD CAP SCREW, 1/2-13
UNC X 4 1/2
HCS-1/2-13-4.50
42 2 HEX HD CAP SCREW, 1/2-13
UNC X 3 1/2
HCS-1/2-13-3.50
43 2 HEX HD CAP SCREW, 1/2-13
UNC x 2 1/2
HCS-1/2-13-2.50
44 8 HEX HD CAP SCREW, 1/2-13
UNC X 1 3/4
HCS-1/2-13-1.75
45 22 HEX HD CAP SCREW, 1/2-13
UNC X 1 1/2
HCS-1/2-13-1.50
46 14 FLAT WASHER, 5/16 FLW-5/16
47 10 FLAT WASHER, 3/4 FLW-3/4
48 20 FLAT SOCKET HD CAP
SCREW 5/16-18 UNC x 1
FCS-5/16-18-1.00
49 8 FLAT SOCKET HD CAP
SCREW 1/2-13 UNC x 2-1/2
FCS-1/2-13-2.50
50 30 ROLL PIN 1/8 x 3/4 DR62311
51 18 BUTTON HD CAP SCREW
5/16-18 UNC x 3/4
BCS-5/16-18-0.75
52 32 WASHER HD THREAD
FORMING SCREW 5/16-18
UNC x 0.50
TFS-5/16-18-0.50
53 4 SQUARE HEAD SET SCREW
7/8-9 UNC x 6
SSS-0.875-9-6.00
54 2 COTTER PIN, 1/8 DIA x 2 CTP-0.125-2.00
