Midland SP-8 - Page 75

69
www.roadwidener.com
Model SP-8 & 10
NO REQ DESCRIPTION PART NUMBER
1 1 HOPPER FRAME SUB-
ASSEMBLY
SP-784
2 2 CLIP, END PLATE SP-885
3 1 WIPER FRAME WELDMENT SP-811
4 1 BIB ASSEMBLEY SP-718
5 1 DEFLECTOR PLATE
INSTALLATION
SP-717
6 1 COVER (HYD HOSES) SP-560
7 1 END PLATE SA-451
8 1 HOPPER END-LEFT SIDE SA-444-02
9 1 HOPPER END-RIGHT SIDE SA-444-01
10 2 DRIVE ROLLER SA-440
11 1 CONVEYOR BELT ASSY, W/
ROLLER CHAIN
SA-1593
12 30 ROLLER SA-1147
13 1 RETAINER - WIPER SA-055
14 1 WIPER RUBBER SA-043
15 1 END COVER SA-033
16 1 ROLLER STUB SHAFT S-438
17 2 MOTOR MOUNT KEEPER S-437
18 1 HYDRAULIC MOTOR MOUNT S-436
19 1 DRIVE SHAFT COUPLING S-435
20 2 SIDE BOARD RUBBER ASSY
(INTERIOR)
S-427
21 1 RETAINER, CENTER BIB S-426
22 1 CENTER BIB S-425
23 1 BUMPER & GUIDE WELDM’T S-422
24 2 SIDE BOARD RUBBER W/
NOTCHES (EXTERIOR)
S-1612
25 1 REAR SIDE BOARD S-1399
26 1 FRONT SIDE BOARD S-1398
27 4 CLAMP, RUBBER SIDEBOARD S-1382
28 1 MOTOR, HYDRAULIC (CONV.
DRIVE)
M8033
29 3 BEARING, TAKE-UP SC 2”
BORE
M0146
30 4 LOCK WASHER, 5/16 LKW-5/16
31 22 LOCK WASHER, 3/8 LKW-3/8
32 10 LOCK WASHER, 3/4 LKW-3/4
33 53 LOCK WASHER, 1/2 LKW-1/2
34 10 HEX NUT, 3/8-16 UNC HXN-3/8-16
35 6 HEX NUT, 3/4-10 UNC HXN-3/4-10
36 31 HEX NUT, 1/2-13 UNC HXN-1/2-13
37 4 HEX JAM NUT, 7/8-9 UNC HJN-7/8-9
38 4 HEX HD CAP SCREW, 5/16-18
UNC-1 3/4
HCS-5/16-18-1.75
39 6 HEX HD CAP SCREW, 3/8-16
UNC x 2
HCS-3/8-16-2.00
40 4 HEX HD CAP SCREW, 3/8-16
UNC X 1 3/4
HCS-3/8-16-1.75
41 12 HEX HD CAP SCREW, 3/8-16
UNC X 1 1/4
HCS-3/8-16-1.25
42 6 HEX HD CAP SCREW, 3/4-10
UNC x 6
HCS-3/4-10-6.00
NO REQ DESCRIPTION PART NUMBER
43 2 HEX HD CAP SCREW 3/4-10
UNC x 3-1/2
HCS-3/4-10-3.50
44 2 HEX HD CAP SCREW 3/4-10
UNC x 2-1/2
HCS-3/4-10-2.50
45 2 HEX HD CAP SCREW, 1/2-13
UNC X 4 1/2
HCS-1/2-13-4.50
46 2 HEX HD CAP SCREW, 1/2-13
UNC X 3 1/2
HCS-1/2-13-3.50
47 3 HEX HD CAP SCREW, 1/2-13
UNC x 2 1/2
HCS-1/2-13-2.50
48 4 HEX HD CAP SCREW, 1/2-13
UNC X 1 3/4
HCS-1/2-13-1.75
49 22 HEX HD CAP SCREW, 1/2-13
UNC X 1 1/2
HCS-1/2-13-1.50
50 14 FLAT WASHER, 5/16 FLW-5/16
51 15 FLAT WASHER, 3/8” FLW-3/8
52 10 FLAT WASHER, 3/4 FLW-3/4
53 20 FLAT SOCKET HD CAP
SCREW 5/16-18 UNC x 1
FCS-5/16-18-1.00
54 7 FLAT SOCKET HD CAP
SCREW 1/2-13 UNC x 2-1/2
FCS-1/2-13-2.50
55 12 FLAT HD CAP SCREW, 1/2-13
UNC X 1.00
FCS-1/2-13-1.00
56 18 BUTTON HD CAP SCREW
5/16-18 UNC x 3/4
BCS-5/16-18-0.75
57 32 WASHER HD THREAD
FORMING SCREW 5/16-18
UNC x 0.50
TFS-5/16-18-0.50
58 5 WASHER HD THREAD
FORMING SCREW 3/8-16 UNC
x 1
TFS-3/8-16-1.00
59 4 SQUARE HEAD SET SCREW
7/8-9 UNC x 6
SSS-0.875-9-6.00
60 30 ROLL PIN 1/8 x 3/4 DR62311
61 1 COTTER PIN, 1/8 DIA x 2 CTP-0.125-2.00
