OM-363 Page 68
Description
Part
No.
Dia.
Mkgs.
Item
No.
Figure 11-1. Main Assembly (continued)
Quantity
250
DX
350
LX
Model
103 PC3♦♦195 345 CIRCUIT CARD ASSY, SEQUENCER (INCLUDES) 1 1. . . . . . . . . . . . . . . . . . . . . . . . . . .
215 441 CIRCUIT CARD, SEQUENCER 1 1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
183 332 KNOB, POINTER .570 DIA X .125 ID W/SPRING CLIP 5 5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
104
♦Figure 11-3 TIGRUNNER RUNNING GEAR 1 1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
108 CR2 059 266 RELAY, ENCL 120VAC DPDT 10A/120VAC 8PIN 1 1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
♦194 744 RFCS−14HD (FOOT CONTROL) 1 1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
109 222 451 BRACKET, RELAY 1 1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
110 137761 NUT, 750 NPT 1.31HEX .27H NYL BLK 1 1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
111 035 704 RECTIFIER, INTEG BRIDGE 40. AMP 800V 1 1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
112 230 155 BRACKET, VALVE MOUNT 1 1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
+When ordering a component originally displaying a precautionary label, the label should also be ordered.
♦Part of TIGRUNNER option.
♦♦Field option only.
To maintain the factory original performance of your equipment, use only Manufacturer’s Suggested
Replacement Parts. Model and serial number required when ordering parts from your local distributor.
