Electrical and Pneumatic Connections Theory of Operation
1 - 12 046-001141-00 A5/A3™ Service Manual
74 Y2 Y2 082-000522-00
75 O2 Poppet Valve Y2 082-000522-00
76 O2 Poppet Valve Y2 082-000522-00
77 Y2 O2 Poppet Valve 082-000522-00
78 Y2 O2 Flow Sensor 082-000522-00
79 Y1 O2 Pipeline Assembly 082-000521-00
81 Y1 Y1 082-000521-00
90 Air Needle Valve Restrictor Assembly 082-000520-00
91 N2O Needle Valve N2O Flow Sensor 082-000524-00
Y1 Three-way Connector 082-000583-00
Y2 Three-way Connector 082-000582-00
