Mindray A3 - Remove the Breathing Tubes

Disassemble the Breathing System Repair and Disassembly
6 - 48 046-001141-00 A5/A3™ Service Manual
6.3.2 Remove the Breathing Tubes
NOTE: When disassembling the breathing tube, hold the tube connectors at
both ends of the tube to prevent damage to the tube.
1. Remove the filter from the Y piece.
FIGURE 6-91
2. Disconnect the breathing tubes from the inspiration/expiration connectors on the circuit.
FIGURE 6-92
