Disassemble the Breathing System
Repair and Disassembly
6 - 62
046-001141-00
A5/A3™ Service Manual
FIGURE 6-119
6.3.15
Remov
e
the F
ront Upper C
ov
er
, Median Plate and F
ront
Lo
wer C
over Assemblies
1.
Remove the Back
Upper Cover and Back L
ower Cover As
semblies as per section 6.3.16.
2.
Remove the two scr
e
ws on the low
er cover
.
FIGURE 6-120
3.
Loose
n the six screws on the u
pper cove
r
.
401
403
