A5/A3™ Service Manual 046-001141-00 1 - 15
Theory of Operation Electrical and Pneumatic Connections
69 Y1 Auxiliary Gas Outlet 082-000521-00
73 O2 Needle Valve Y2 082-000522-00
74 Y2 Y2 082-000522-00
75 O2 Poppet Valve Y2 082-000522-00
76 O2 Poppet Valve Y2 082-000522-00
77 Y2 O2 Poppet Valve 082-000522-00
78 Y2 O2 Flow Sensor 082-000522-00
79 Y1 O2 Pipeline Assembly 082-000521-00
81 Y1 Y1 082-000521-00
90 Air Needle Valve Restrictor Assembly 082-000520-00
91 N2O Needle Valve N2O Flow Sensor 082-000524-00
Y1 Three-way Connector 082-000583-00
Y2 Three-way Connector 082-000582-00
S/N From To P/N
