A5/A3™ Service Manual 046-001141-00 1 - 17
Theory of Operation Electrical and Pneumatic Connections
S/N From To P/N
1 Exhalation Gas Assembly Flow Sensor connector A21-000007---
2 Exhalation Gas Assembly Hardware Box Connector A21-000007---
3 Exhalation Gas Assembly Flow sensor connector A21-000007---
4 Three-way Valve Ventilator Control Board A21-000007---
5 Three-way Valve Y2 A21-000007---
6 Three-way Valve Ventilator Control Board A21-000007---
7 Three-way Valve Y2 A21-000007---
8 Y2 Ventilator Control Board A21-000007---
9 Y2 Ventilator Control Board A21-000007---
10 Hardware Box Connector Y1 A21-000007---
11 Y1 Breathing System Connector M6G-020046---
12 Hardware Box Connector Y1 A21-000007---
13 Y1 Breathing System Connector M6G-020046---
14 Hardware Box Connector Y1 A21-000007---
15 Y1 Breathing System Connector M6G-020046---
16 Hardware Box Connector Y1 A21-000007---
17 Y1 Breathing System Connector M6G-020046---
18 Exhalation Gas Assembly Gas Reservoir 082-002365-00
22
Gas-out Connector of CGO
Connector
Fresh Gas 082-000519-00
23 Breathing System Connector Exhalation Gas Assembly 115-034448-00
24 Breathing System Connector Gas Reservoir 115-034449-00
72 Hardware Box Connector Ventilator Control Board A21-000007---
80 Hardware Box Connector Ventilator Control Board A21-000007---
82 Hardware Box Connector Ventilator Control Board A21-000007---
84 Hardware Box Connector Ventilator Control Board A21-000007---
86 Hardware Box Connector Y2 A21-000007---
88 Y2 Three-way Valve A21-000007---
Y1 Two-way Connector M02A-10-25945
Y2 Three-way Connector M90-100030---
To Next Page
