A5/A3™ Service Manual
046-001141-00
6 - 41
Repair and Disassembly
Disassemble the Assemblies
6.2.7.1
Remo
ve the Pr
essure Gauges
1.
Remove the pr
essure gauge panel.
2.
Unscrew the
12 screws on the pr
essure gauges
t
o remove both the supply gas gauges and the
high-pr
essure gau
ges.
FIGURE 6-76
6.2.7.2
Remo
ve the
T
otal Flowmeter
1.
Remove the met
er panel.
2.
Remove the fo
ur screws on the total flowmeter and to remov
e
it.
FIGURE 6-77
