Introduction Replacement Parts
7 - 4 046-001141-00 A5/A3™ Service Manual
/ Drawer rail 031-000041-00
9 Total Flow meter 801-0631-00008-00
9a Total Flowmeter Cover 043-000787-00
10 N2O Pressure Gauge Assembly (0~140psi) 115-024842-00
11 Air Pressure Gauge Assembly (0~140psi) 115-024843-00
12 System Switch Knob 801-0631-00012-00
13 O2 Pressure Gauge Assembly (0~140psi) 115-024841-00
14 Storage Mount for Vaporizer (A5 only) 801-0631-00076-00
15
Two Vaporizer Mounting Manifold or
Three Vaporizer Mounting Manifold
801-0631-00024-00 or
115-020218-00
16 O2 Flush Button
043-001124-00(FDA)
043-001818-01(Canadian)
17 A-Series Handrail 042-002357-00
18 Pressure Gauge Panel
043-001122-00(A3 and Original A5, FDA)
043-001122-01(New A5 Only, FDA)
043-003521-00(Canadian)
19 O2 Sensor Cover(Include two covers) 115-016612-00
33 Vacuum Suction Tube Fixing Clamp 043-003125-00
34
A5 front panel under work surface 043-000794-00
A3 front panel under work surface 043-001809-00
35 Front cover of main unit 043-001120-01
36 Top cover screw paster 047-007458-00
37 Display panel
043-003173-00 (A5)
043-003534-00 (A3 and original A5)
FIG.NO. DESCRIPTION PART NUMBER
