A5/A3™ Service Manual 046-001141-00 7 - 21
Replacement Parts Introduction
7.1.2.16 O-rings (A5/A3)
NO. DESCRIPTION PART NUMBER REMARK
1 Seal,valve port 049-000140-00 for CO2 Bypass shaft
2 Gasket, CO2 bypass assembly 049-000142-00 \
3 Gasket, absorber canister exterior 049-000143-00 \
4 Gasket, absorber canister interior 049-000145-00 \
5 CO2 Absorber Hose 049-000146-00 \
6 Bellow check valve membrane 049-000240-00 \
8 Gasket, bellows canister base 049-000243-00 \
9 AGSS filter 082-000506-00 \
10 O-ring 14X2.65 082-000934-00 for Vaporizer mount
11 O-ring 30X2 082-000624-00 bag arm base
12 O-ring 25X2 082-000625-00 APL valve
13 O-ring 27X1.5 082-001501-00 for Check valve dome
14 O-ring 18X2.5 082-000627-00 Breathing system base
15 O-ring 20X1.5 082-001503-00 for Check valve
16 O-ring 23.47X2.95 082-001504-00
for Water Collection Cup + CO2 Bypass
Assembly
17 O-ring 52X2 082-000630-00 Auto/Manual ventilation switch
18 O-ring 29X2.62 082-000633-00 Bellows base
19 O-ring 6.07X1.78 082-000641-00 Bottom of the breathing system cover screw
20 O-ring 29.82X2.62 082-000642-00 APL valve
21 O-ring 40X2.2 082-000648-00 Auto/Manual ventilation switch
22 O-ring 8.5X2.0 082-001525-00 O2 cell port
23 O-ring 8.5X2 082-000665-00 for rotating block of breathing circule
24 O-ring 4.7X1.8 082-000667-00 for rotating block of breathing circule
25 O-ring 6X1 082-000669-00 for Auto/Manual ventilation switch
26 O-ring 15.54X2.62 082-000673-00 for bag arm +O2 cell cover
27 O-ring 4.47X1.78 082-000679-00 for CO2 Bypass shaft
28 O-ring (for airway pressure gauge) 801-0631-00118-00 \
29 O-ring 16X2 M6M-010058--- for rotating block of breathing circle
30 O-ring 10.72X1.78 082-001524-00 for airway pressure gauge
31 O-ring 0.35X1.78 FKM A70 082-000676-00 \
Not
Shown
Maintenance Kit for O-rings 801-0631-00141-00 \
To Next Page
