A5/A3™ Service Manual 046-001141-00 1 - 47
Theory of Operation Ventilator UI
FIGURE 1-46 Indicator Light Board, Bottom View
Indicator Light Board interface, J1
PIN NAME FUNCTION
1 LED_AC AC Indicator Light Drive Signal
2 LED_BAT Battery Indicator Light Drive Signal
3GND Ground
