Operator’s Manual of Anesthesia System 10 - 5
Product Specifications Physical Specifications
Top Shelf: Weight limit: 15kg (33 lbs)
Width: 480mm (19 in)
Depth: 310mm (12 in)
Side Mounting Rails: Supporting weight: 27 kg (60 lbs) from a GCX-compatible
rail at a maximum distance of 0.41m with a safety factor of 6
times the weight
Bag Arm: Fixed Height Bag Arm:
Length: 312 mm (12 in)
Height: 1130 mm (44 in)
Swiveling angle: ± 120 degrees
Flexible Bag Arm:
Length: 550mm (22 in)
Flexible bag arm shall be adjusted the height and the angle
freely.
Drawers (internal dimensions): Weight limit: 5 kg (11 lbs)
Drawers are of equal size:
• Height: 140 mm (6 in)
• Width: 420 mm (17 in)
• Depth: 315 mm (12 in)
Caster: 4 casters
Diameter: 125 mm (5 in)
Brake: central brake system with lock/unlock indicator
Cable pusher: cable pusher with each caster
System Noise (under the typical
working mode):
≤42dB(A)
TABLE 10-3 Physical Specifications
