4 - 36
Operator’
s Manual of Anesthesia
System
4.7.8.2
S
etup
Figure 4-38
Setup > System > Setup menu
MENU
OPTION
DESCRIPTION
V
entilation
Insp Pressure
When [
Insp Pressure
] is set to [
Pinsp
], the
inspiration pressure p
arameter in the PCV and SIMV-
PCV ventilation modes is [
Pinsp
]. When
[
Insp
Pressure
] is set to [
ΔPinsp
], the inspiration pr
essure
parameter i
n the PCV a
nd SIMV-PCV ve
ntilation
modes is [
ΔPinsp
].
T
able 4-7
Setu
p menu
93
95
