Mindray A8 - Breathing System Specifications

Breathing System Specifications Product Specifications
10 - 10 Operator’s Manual of Anesthesia System
10.7.2 Volume Exchanger Volume
10.7.3 CO
2
Absorber Assembly
10.7.4 Breathing System Connections
Volume:
1500mL
TABLE 10-14 Volume Exchanger Volume
Absorber Capacity: 1 Pre-Pak (1500ml)
Absorber Canister Contents: 1 Pre-Pak canister or Loose Fill absorbent
TABLE 10-15 CO
2
Absorber Assembly
Exhalation Connection: Coaxial 22mm male/15mm female conical connector
complying with ISO 5356-1
Inhalation Connection: Coaxial 22mm male/15mm female conical connector
complying with ISO 5356-1
Manual bag connection: Coaxial 22mm male/15mm female conical connector
complying with ISO 5356-1
Exhaust port: 30mm male conical connector complying with ISO 5356-1
TABLE 10-16 Breathing System Connections
