Operator’s Manual of Anesthesia System 10 - 9
Product Specifications Breathing System Specifications
10.6.2 Cylinder Supply
10.6.3 Auxiliary Common Gas Outlet (ACGO)
10.6.4 Anesthetic Vaporizer
10.6.5 Drive Gas
O
2
10.6.6 O
2
Controls
O
2
supply failure alarm: ≤220.6kPa±34.2kPa
10.7 Breathing System Specifications
10.7.1 Breathing System Volume
Cylinder Supply: E-cylinder (American style) and pin indexed per CGA V-1
O
2
Cylinder Input Pressure Range: 6.9 to 20.0 MPa (1000 to 2900 psi)
N
2
O Cylinder Input Pressure Range: 4.2 to 6.0 MPa (600 to 870 psi)
Air Cylinder Input Pressure Range: 6.9 to 20.0 MPa (1000 to 2900 psi)
Cylinder Input Flow Rate Range: O
2
: V'max. 190L/min
Air: V'max. 70L/min
N
2
O: V'max. 20 L/min
Cylinder Connections: Pin-Index Safety System (PISS)
Yoke Configuration: O
2
, Air, N
2
O
TABLE 10-10 Cylinder Supply
Control type Mechanical
Connector: Coaxial 22mm male/15mm female conical connector
complying with ISO 5356-1
Safety Pressure: A pressure relief valve limits fresh gas pressure at the ACGO
outlet port to not more than 12.5 kPa.
Fresh Gas Flow: 0.00 to 20.0 L/min
TABLE 10-11 ACGO
Vaporizer Positions: Double
Mounting Mode:
SELECTATEC®, with interlocking function (SELECTATEC® is
registered trademark of Datex-Ohmeda Inc.)
TABLE 10-12 Selectatec® Anesthetic Vaporizer
Mechanical Ventilation: Approx. 1800mL (Including CO
2
absorbent, not including
volume exchanger)
Manual Ventilation: Approx. 1950mL (Including CO
2
absorbent and bag arm, not
including manual bag)
TABLE 10-13 Breathing System Volume
