Operator’s Manual of Anesthesia System 10 - 15
Product Specifications Monitor Module
10.10 Monitor Module
10.10.1 AG Module
Flow Input Range: 20 L/min to 40 L/min
Maximum Vacuum: 69 kPa to 72 kPa (517.5 mmHg to 540 mmHg) with external
vacuum applied of 72 kPa (540 mmHg) and 40 L/min free
flow
Maximum Flow: 39 L/min to 40 L/min with external vacuum applied of 72
kPa (540 mmHg) and 40 L/min free flow
Minimum Flow: 20 L/min
Vacuum Gauge Accuracy: ± 5 % of full scale
TABLE 10-22 Suction device
Warm-up time: ISO accuracy mode: < 45 s
Full accuracy mode: <10 min
Sampling rate: Sampling rate:
Adult/Pediatric AG watertrap and sample line: 150/180/200 ml/min
Neonate AG watertrap and sample line: 100/110/120 ml/min
Accuracy: ± 10 ml/min or ± 10 % of the setting value, whichever is
greater
Watertrap emptying interval
1
Adult/Pediatric AG watertrap:
≥19h@150ml/min
≥18h@180ml/min
≥17h@200ml/min
Neonate AG watertrap:
≥24h@100ml/min
2
≥22h@110ml/min
≥20h@120ml/min
Gas: CO
2
, O
2
, N
2
O, and any of the five anesthetic agents: DES, ISO, ENF, SEV
and HAL.
Range: CO
2
: 0.0 to 30 % (0 to 30kPa, 0 to 226mmHg)
O
2
: 0 to 100 %
N
2
O : 0 to 100 %
DES : 0.0 to 30 %
SEV : 0.0 to 30 %
ENF : 0.0 to 30 %
ISO : 0.0 to 30 %
HAL : 0.0 to 30 %
TABLE 10-23 AG Module
