Operator’s Manual of Anesthesia System 3 - 11
Installation and Disassembly Connect Anesthesia System with Information System
3.8 Connect Anesthesia System with Information
System
3.8.1 Connect Anesthesia System with Information System Through
Serial Interface
The anesthesia system can be connected to the information system through a serial interface and
send its ventilation modes, status, parameters, alarms, alarm limits and patient information to the
information system by the HL7 protocol.
1. The communication cable is connected to the communication interface of the anesthesia
system on one end and connected to the matched interface of the information system on the
other end.
2. Select the icon to open the [Setup] menu.
3. Select the [System] soft key, enter the system password and confirm the password.
4. Select the [Network] tab in the system menu.
5. Select the [Serial] tab.
6. Set [Protocol] to [HL7].
7. Configure related settings. See 4.7.8.4 (Pages 4-41) "Network".
3.8.2 Connect Anesthesia System with Information System Through
Ethernet
The anesthesia system can be connected to the information system through ethernet and send its
ventilation modes, status, parameters, alarms, alarm limits, patient information and waveforms to the
information system by the HL7 protocol.
1. The network cable is connected to the ethernet interface of the anesthesia system on one end
and connected to the matched interface of the information system on the other end.
2. Select the icon to open the [Setup] menu.
3. Select the [System] soft key, enter the system password and confirm the password.
4. Select the [Network] tab in the system menu.
5. Select the [HL7] tab.
6. Configure related settings. See 4.7.8.4 (Pages 4-41) "Network".
NOTE: The IP addresses of the anesthesia system and the information
system must be in the same segment.
