Operator’s Manual of Anesthesia System C - 3
Operating Principles Pneumatic Diagram
SERIAL
NO. MODULE
SERIAL
NO. MODULE
SERIAL
NO. MODULE
1.1 Filter 6 High-Pressure O2
Output
17.1 Flow Restrictor
1.2 Check Valve 7 O2 Flush 17.2 ACGO Switch
1.3 Pressure Switch 8 System Switch 17.3 11kPa Pressure
Relief Valve
1.4 Pressure Relief Valve 9.1 Pilot-Operated Valve
of Manual/Auto
Switch
17.4 ACGO Port
1.5 Pressure Regulating
Valve
9.2 Pilot-Operated Valve
of AGSS On/Off
18.1 Check Valve
1.6 Cylinder Pressure
Gauge
10.1 Filter 18.2 Airway Pressure
Gauge
1.7 Electronic Pressure
Sensor of Cylinder
10.2 Pressure Regulating
Valve
18.3 O2 Sensor
1.8 Pressure Regulating
Valve of Cylinder
10.3 Proportional Valve 18.4 Differential
Pressure Gauge of
Inspiration
1.9 Check Valve of
Cylinder
10.4 Flow Sensor 18.5 2/3 Switch-Over
Valve
1.12 Electronic Pressure
Sensor of Pipeline
10.5 Filter 18.6 2/3 Switch-Over
Valve
2.1 Filter 10.6 Normally-Closed
Switch Valve
18.7 Inspiration Flow
Sensor
2.2 Electronic Pressure
Sensor of Pipeline
10.7 Pressure Switch 18.8 Pressure Sensor
2.3 Pressure Relief Valve 10.8 Proportional Valve 18.9 Inspiratory Port
2.4 Check Valve 10.9 Flow Restrictor 18.10 Expiratory Port
2.5 Pressure Regulating
Valve
11.1 Check Valve 18.11 Differential
Pressure Gauge of
Expiration
2.6 Cylinder Pressure
Gauge
11.2 O2 Needle Valve 18.12 2/3 Switch-Over
Valve
2.7 Electronic Pressure
Sensor of Cylinder
11.3 Check Valve 18.13 Expiration Flow
Sensor
2.8 Pressure Regulating
Valve of Cylinder
11.4 Air Needle Valve 18.14 Watertrap
2.9 Check Valve 11.5 Float Flowmeter (0-
15LPM)
18.15 Check Valve
3.1 Filter 11.6 Normally-Open
Switch Valve
18.16 Self-Sealing
Sampling Tube
3.2 Electronic Pressure
Sensor of Pipeline
12.1 Filter 18.17 Bypass
3.3 Pressure Relief Valve 12.2 Normally-Closed
Switch Valve
18.18 CO2 Absorber
Canister
3.4 Check Valve 12.3 Check Valve 18.19 Check Valve
3.5 Cylinder Pressure
Gauge
12.4 Proportional Valve 18.20 11kPa Pressure
Relief Valve
To Next Page
