Equipment Views Product Description
2 - 6 Operator’s Manual of Anesthesia System
A22 AC status indicator The indicator is on when the system is connected to an AC
power source.
A23 System switch Used to switch on or off the system.
A24 Key lock The key and lock to lock a drawer.
A25 Gas supply pressure gauge Used to indicate the pressure of the O
2
, air and N
2
O backup
gas cylinders for the anesthesia system.
A26 Volume exchanger cover Pull the unlocking button in the bottom right corner
outward as per instructions on the equipment to open the
volume exchanger cover.
A27 Caster lock Lock/release the brakes for front two casters when
depressed.
A28 Caster The system moves with the help of casters. Caster lock of the
equipment is controlled by the central brake and caster
brake.
A29 Humidifier The humidifier should be connected to the tube when the
High-flow Nasal Cannula Oxygen (HFNC) feature is enabled.
A30 Top Shelf Top shelf surface.
