Operator’s Manual of Anesthesia System 4 - 29
System Interface Setup Menu
Plimit Line
Set the [Plimit Line] to (off ) or (on). The Plimit line function displays a dashed line in
the Pressure waveform area to indicate the Plimit position. The Plimit line can be displayed in VCV,
SIMV-VC, SIMV-VG and PCV-VG modes.
NOTE: The Plimit line does not affect the auto-scaling algorithm. If the Plimit
line is turned on but not visible, it may be because the line is positioned
off the waveform scale.
Breathing System Warmer
The [Breathing System Warmer] can be set to (off ) or (on). If the [Breathing System
Warmer] is (off ), or if AC power is not connected, the system displays an icon to indicate that
the warmer is not active.
After cycling power, the Breathing System Warmer will return to the default state.
NOTE: The Breathing System Warmer is inactive when the equipment is
powered by battery.
