Mindray M9 User Manual

Structure and Assembly/Disassembly 8-7
4. Remove button battery
Hold the button battery gently. Put the sharp end of the tweezers or flat-headed screw into the
gap between battery and bulges of plastic cover. The button battery bounces off then.
Note: do not press hard in the operation.
8.2.5 SSD Card
1. Remove the hard disk cover. See the first step in Chapter 8.2.4.
2. Push the metal clasp towards the blue arrow’s direction.
Two metal snap closure to lock wireless network adaptor
Wireless network adaptor
Metal snap closure
B
ulges of plastic cover

Mindray M9 Specifications

General

Type	Portable Ultrasound System
Battery	Rechargeable lithium-ion battery
Battery Life	Up to 90 minutes
Display	15.6 inch high resolution LED monitor
Imaging Modes	B, M, Color, Power, PW, CW
Transducers	Linear, Convex, Phased Array
Transducer Ports	3
Probe Connectors	3
Connectivity	DICOM, USB, HDMI
Operating System	Windows-based
