Mindray M9 User Manual

9-6 Installation of Option Modules
9.2.4 Trolley Installation
The service staff installs the trolley according to the following steps after receiving the package:
1. Open the package. See Chapter 3.2.1.1 for details.
2. Install the holders on right and left sides.
As shown in the following figure a) and b), place the probe holder into the holes of the left and
right plate of the trolley. The probe holders that are installed are shown in figure c.
Audio/video extender assembly
Metal clip

Mindray M9 Specifications

General

Type	Portable Ultrasound System
Battery	Rechargeable lithium-ion battery
Battery Life	Up to 90 minutes
Display	15.6 inch high resolution LED monitor
Imaging Modes	B, M, Color, Power, PW, CW
Transducers	Linear, Convex, Phased Array
Transducer Ports	3
Probe Connectors	3
Connectivity	DICOM, USB, HDMI
Operating System	Windows-based
