Mindray M9 User Manual

9-2 Installation of Option Modules
 Promote
1. Click [Promote]. The following image appears:
Note: the promotion function is only applied to the uninstalled key. If the optional key is installed,
the promotion function is disabled.
2. Select the key to be promoted.
3. Click [OK] to complete the promotion.
Note:
1.
The optional assembly is limited to single key. If the module is installed or
there are 2 or more than 2 groups of the modules are selected, the installation
button appears dimmed and disabled.
2.
After all modules are installed, please go to the previous interface to confirm.

Mindray M9 Specifications

General

Type	Portable Ultrasound System
Battery	Rechargeable lithium-ion battery
Battery Life	Up to 90 minutes
Display	15.6 inch high resolution LED monitor
Imaging Modes	B, M, Color, Power, PW, CW
Transducers	Linear, Convex, Phased Array
Transducer Ports	3
Probe Connectors	3
Connectivity	DICOM, USB, HDMI
Operating System	Windows-based
