Mindray SV300 User Manual

A-6
A.2.2 Parts List
B1 AC-DC Power board S6 Oxygen proportional valve
B2 Battery adapter board S7 Turbine
B3 DC-DC Power board S8 Temperature sensor
B4 Main control board S9 Inspiration valve
B5 Monitoring module S10 Expiration valve
B6 Vacuum sensor board S11 Speaker
B7 Sensor adapter board S12 Display
B8 Coder board S13 O
2
sensor
B9 Alarm light board S14 Oxygen flow sensor
B10 Key board S15 Total flow sensor
S1 Total AC input and fuse B16 Safety valve
S2 External DC-IN S17 Touch screen
S3 Battery S18 Sidestream CO
2
Module
S4 Radiator fan S19 Mainstream CO
2
Module
S5 Nebulizing valve S20 SpO
2
module

Mindray SV300 Specifications

General

Waveform Display	Pressure, Flow, Volume
Battery Backup	Up to 2 hours
Ventilation Modes	VCV, PCV, SIMV
Tidal Volume Range	20 to 2000 mL
FiO2	21 to 100%
Inspiratory Time	0.2-5.0 s
Monitoring Parameters	Paw, Ppeak, Pmean, Pplat, PEEP, VTI, VTE, MV, f, FiO2, I:E
Alarms	High/Low Airway Pressure, High/Low Minute Volume, High/Low Tidal Volume, High/Low Respiratory Rate, High/Low FiO2, Apnea, Power Failure
Power Supply	AC 100-240V, 50/60Hz
Peak Flow	180 L/min
Trigger Sensitivity (Flow)	0.5-10 L/min
